Architectural
AR1015
AR1015 — Architectural Ring The AR1015 is a architectural ring style LED luminaire, supplied complete with 45W, 3470 - 4630 lm at ~100 lm/W (estimated), avai...
IP20
MOUNTRecessed
BUILD YOUR SPECIFICATION
WATTAGE (W)
DRIVER
COLOUR RENDERING (CRI)
COLOUR TEMPERATURE (K)
BEAM ANGLE
BODY COLOUR
IP RATING
EMERGENCY
YOUR EMPRICS SKU
AR1015.00X000.00XXXX.00
Select your options above to build a specification.
AVAILABLE OPTICS & ACCESSORIES
Your quote list
Technical Specification AR1015
Construction
| Type | Architectural Ring |
|---|---|
| Installation | Recessed |
| Housing Material | Aluminium |
| Finishes | White, Black, Grey |
| Dimensions | See datasheet |
| Cutout | See datasheet |
| Weight | 4.5-5.8 kg |
Photometric
| Light Source | LED |
|---|---|
| Luminous Flux | 3470 - 4630 lm |
| Efficacy | ~100 lm/W (estimated) |
| Colour Rendering | CRI80, CRI90, CRI95+ |
| Colour Temperature | 3000K, 4000K |
| Beam Distribution | Direct |
| Light Distribution | Direct |
| MacAdam | 3 SDCM |
Electrical
| Power Range | 45W |
|---|---|
| Voltage | 220-240V AC |
| Control Gear | Fixed Output (F), DALI2 (D), Wireless (W) |
| Emergency | None, 3hr Standard, 3hr DALI2, 3hr Self-Test, 3hr Wireless |
| Flux Tolerance | +/-10% |
Compliance & Lifetime
| Ingress Protection | IP20 |
|---|---|
| Impact Resistance | IK04 |
| Protection Class | Class I / Class II |
| Certification | CE Marked |
| L80B10 Lifetime | 100,000 hrs |
| L90B10 Lifetime | 75,000 hrs |
Optic Options
| Available Optics | - |
|---|
Technical Downloads
