Architectural

AR1016

AR1016 — Architectural Ring The AR1016 is a architectural ring style LED luminaire (nominal 400 x 400 x 62mm), supplied complete with 13 W, 1150 - 1180 lm at...

DIM400 x 400 x 62 mm

IP20

MOUNTRecessed

BUILD YOUR SPECIFICATION

WATTAGE (W)

DRIVER

COLOUR RENDERING (CRI)

COLOUR TEMPERATURE (K)

BEAM ANGLE

REFLECTOR / DIFFUSER

BODY COLOUR

IP RATING

EMERGENCY

YOUR EMPRICS SKU AR1016.00X000.00XXXX.00

Select your options above to build a specification.

Download Datasheet

AVAILABLE OPTICS & ACCESSORIES

YOUR EMPRICS SKU

AR1016.00X000.00XXXX.00

Guide pricing

POA

Technical Specification AR1016

Construction

Type	Architectural Ring
Installation	Recessed
Housing Material	Aluminum
Finishes	Black, Grey, White
Dimensions	400 x 400 x 62 mm
Cutout	See datasheet
Weight	2.8 kg

Photometric

Light Source	LED
Luminous Flux	1150 - 1180 lm
Efficacy	88-91 lm/W
Colour Rendering	80
Colour Temperature	2700K, 3000K, 3500K, 4000K, 5000K, 6000K
Beam Distribution	15°, 24°, 36°
Light Distribution	DI
MacAdam	SDCM 3

Electrical

Power Range	13 W
Voltage	220 ... 240 V
Control Gear	Fixed Output (F), DALI2 (D), Wireless (W)
Emergency	None, 3hr Standard, 3hr DALI2, 3hr Self-Test, 3hr Wireless
Flux Tolerance	+/-10%
