Architectural

AR1022

AR1022 Recessed Linear DownlightEvery option below carries its own EMPRICS code. Quote the code for an exact specification, or call T: +44 (0) 330 174 4444 f...

IP20

MOUNTSurface, Suspended, Recessed

BUILD YOUR SPECIFICATION

WATTAGE (W)

DRIVER

COLOUR RENDERING (CRI)

COLOUR TEMPERATURE (K)

BEAM ANGLE

REFLECTOR / DIFFUSER

BODY COLOUR

IP RATING

EMERGENCY

YOUR EMPRICS SKU AR1022.00X000.00XXXX.00

Select your options above to build a specification.

Download Datasheet

AVAILABLE OPTICS & ACCESSORIES

YOUR EMPRICS SKU

AR1022.00X000.00XXXX.00

Guide pricing

POA

Technical Specification AR1022

Construction

Type	Architectural Ring
Installation	Surface, Suspended, Recessed
Housing Material	Aluminium
Finishes	White, Black, Grey

Photometric

Luminous Flux	1450 - 4650 lm
Efficacy	~100 lm/W (estimated)
Colour Rendering	CRI80, CRI90
Colour Temperature	2700K, 3000K, 3500K, 4000K, 5000K, 6000K
Beam Distribution	Wide, Direct
Light Distribution	Direct
MacAdam	3 SDCM

Electrical

Voltage	220-240V AC
Control Gear	Fixed Output (F), DALI2 (D), Wireless (W)
Emergency	None, 3hr Standard, 3hr DALI2, 3hr Self-Test, 3hr Wireless
Flux Tolerance	+/-10%

Compliance & Lifetime

Ingress Protection	IP20
Impact Resistance	IK04
Protection Class	Class I
Certification	CE Marked
L80B10 Lifetime	100,000 hrs
L90B10 Lifetime	75,000 hrs

Optic Options

Available Optics	Opal, Frosted

Technical Downloads

Product Datasheet

PDF

Project Installations

PROJECT PHOTO

Configure your code

Choose each option to build a valid product code. Copy the code and description into your specification, download the photometric file, or send the code for a quotation.

Loading the configurator…
